UMZV6-3FST30TN
UP-Zählerverteiler+PW+UM Steiermark
für TN-Netz, außen B1501xH1089xT245mm
Read moreScope of delivery
- Putzwanne
- Rückwand
- Türrahmen
- Türe mit versenkten Scharnieren
- Drehriegelverschluss
- Zählerverteilereinsatz
- Vorzählerfachtüre
- Fe Berührungsschutzabdeckungen
- Anzahl der Nachzählerreihen: 1x 68TE
Dimensions (mm)
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Warning: This option is not available in the current configuration.
Material
Door option
Warning: This option is not available in the current configuration.
€2,145.19
List price
UMZV, Unterputz-Zählerverteiler Steiermark, BxHxT: 1501x1089x245mm, Stahlblech, Türe 2-flügelig, Öffnungswinkel der Türen 122°. Max. Schutzart IP 30.
- Article number
- UMZV6-3FST30TN
- Unit
- Stk
- Door design
- Türe 2-flügelig
- Width
- 1501
- Height
- 1089
- Depth (in mm)
- 245
- Number of counter spaces
- 6
- Material
- Stahlblech
- Max protection type
- IP 30
- RAL Farbe
- RAL 7035
- IK code
- IK 10
- EAN
- 9006203113234
- Commodity code
- 85381000
- Country of origin
- AT
- Net weight
- 65,3 kg
- ETIM 9.0
- EC000248
